Analogue Signal Processing Kit

Order Code: 22235521.1.12

Category: General Lab Equipment I

With this board the students can study the operating principle of analog communication systems. Specification: Reference power supply unit Real-time Analog computational unit One-quadrant multiplication unit One-quadrant division unit ...



SPECIFICATION

With this board the students can study the operating principle of analog communication systems.

Specification:

  1. Reference power supply unit
  2. Real-time Analog computational unit
  3. One-quadrant multiplication unit
  4. One-quadrant division unit
  5. Root circuit
  6. Power circuit
  7. Log ratio operation with thermic compensation
  8. Antilog operation with thermic compensation
  9. Attenuator
  10. Amplitude modulation and demodulation
  11. Non inverting summing block
  12. Difference amplifier
  13. Integrator
  14. Differentiator (Shunt)
  15. Base frame with power supply (completed with connecting cable
  16. Complete with a Student Navigator software that allows students to perform their learning activities through a Personal Computer
  17. Complete with theoretical and practical manual
