Repulsion Motor Trainer

Order Code: 46811

Category: Electrical Machine Lab

SALIENT FEATURES : 01 Facilitates  easy and  safe  wiring  by students  due  to  use  of  4mm  sturdy Shrouded banana patch cords  & shrouded socket arrangements. 02 All  machines ...



SPECIFICATION

SALIENT FEATURES :

01 Facilitates  easy and  safe  wiring  by students  due  to  use  of  4mm  sturdy Shrouded banana patch cords  & shrouded socket arrangements.

02 All  machines are mounted on finely painted sturdy base frame with easy machine interchangeability. Use of gear coupling facilitates screwless coupling. interchangeability. Use of gear coupling facilitates screwless coupling.

03 With due emphasis on student safety machines operate upto 300W power levels  and  upto 1500 RPM, without compromising on didactic use. Able to draw all graphs.

04 Trunnion mounted DC Integrated machine is used as Dynamometer for loading other machines (Motors /  generators both); unlike magnetic powder  brake  or  eddy  current  brake which can load only coupled Motors and not generators, with facility to measure shaft power using electronic torque / speed Measurement



Replution Motor Trainer

Name of the Experiments :-

Experiment-1 Study of speed torque characteristics of Repulsion motor.

Experiment-2 Study of efficiency and input power factor measurement of single phase Repulsion motor.

Experiment-3 Speed control and reversal of direction of rotation of repulsion motor.



PANELS PROVIDED

01 Aluminum Machine trainer Rack

02 Multifunction Meter (Single Phase/Three Phase AC 50Hz)

03 DC voltmeter & Ammeter and Torque Measurement Meter

04 Variable DC Power Supply

05 Input Single Phase DOL Starter Panel AC DC Fix / Variable Supply

06 DC Load Resistor

07 Extension Board



MOTORS PROVIDED

1 Repulsion Motor with loading arrangement



ACCESSORIES PROVIDED

01 Hand held digital Tachometer

02  Shrouded connecting leads 4mm 50 / 100cm assorted Red & Black
