Nano  58014  is  a  conventional  laboratory equipment,  not  only  widely  used  in  molecular biological experiments, such as DNA, RNA, protein detection, but also used in absorbance detection for the general substance analysis. It includes three ommon detections to the nucleic acids, nucleic acid markers and proteins.
The variable path length of Nano Ready realizes both the minimum sample volume detection as low as 0.5pL, suitable for precious samples, and th edetection  to  the  high  concentration  samples without dilution at all. Including the liquid drop, it builds in the standard cuvette detection module for more use.

FEATURES
High sensitivity
2028 linear CCD detection unit, new generation product, has higher sensitivity, accuracy as well as repeatability.
Stability for the long life
Long-life xenon flash lamp of Hamamastu ensures stability of detection and the long life of instrument. The  lifting  detection  base  with  sliding  bearing structure has high precision, not easy to damage.
Variable path length
The mini. detection pathlength is 0.05mm; samples with high concentration can be detected directly without dilution.
The  max.  —15000ng/  pL  dsDNA,  the  smallest detection volume of precious samples is 0.5
The  user-defined  settings  are  allowed  if  the pathlength is more than 1 mm.The instrument has flexible and convenient detection function.
Ultra wide wavelength range
With continuous wavelength range as 185-910nm, the instrument can detect various samples through selecting  any  band.  It  adapts  to  a  variety  of detection requirements with wide range of near infrared wavelength.

ACCURATE PATHLENGTH
The stepper motor combined unique double track technology (DPTL), allows the precision of optical pathlength as 0.001mm, thus to achieve highly repeatability of absorbance detection.

CUVETTE DETECTION MODE
The cuvette detection mode comes with magnetic stirring function. User can set the heating functionand stirring speedfor dynamic analysis detection. And the user can define different pathlength, such as 1mm, 2mm, 5mm,10mm. (for Model:FC-1100 only)

UNIQUE DESIGNED PIPETTE HOLDER FOR EASY SAMPLE ADDING
Auxiliary holder for adding liquid can ensure the accuracy of adding liquid during micro measurement. It is also suitable for other m a i n s t r e a m b r a n d s o f m i c r o U V - V i s Spectrophotometerin the market to achieve a stable and simple process of adding liquid.

USER-FRIENDLY SOFTWARE
The simple designed interface makes the software user friendly. It will save the detection data and name file automatically, and it is easy to review the files. There is no need to worry about the loss of experimental data. Set U disk upgrade interface, and maintain the latest and most complete function at any time

WIRELESS CONNECTION
WiFi connected PAD to control the detection and results display and storage without need the cables. Dynamic detection realizes remote controlling and timing reading the results without manual intervention.

MULTI-FUNCTIONS
Nucleic acid detection
Built-in common calculation formula of dsDNA,ssDNA,RNA,Oligo-DNA,Oligo-RNA, can get the concentration and purity of samples automatically.
UV visible custom scanning
In the full wavelength range, set the detected wavelength through increasing or decreasing wavelength with 1 nm as expected.
Protein detection
Can detect the concentration of protein solution, or detect protein concentration of dye marker. Built-in common detection methods of BCA, Bradford, Lowry, Pierce 660nm.
Nucleic acid fluorescence marker detection
Preinstall extinction factor of commonly used fluorescent dyes of dsDNA,ssDNA,RNA,Oligo-DNA,Oligo-RNA.
Cell detection
Can detect absorbance value at 600nm automatically. Meanwhile, it can detect absorbance value at any band under set wavelength range.

TECHNICAL SPECIFICATION
Detector : 2048-element liner CCD array
Mini.Sample Amount (mi)    : 0.5
Mini. Pathlength (mm) : 0.05
Wavelength Range (nm) : 185-910
Wavelength Accuracy (nm) : ±1
Spectral Resolution (nm) : 1.8(FWHMat Hg 253.7nm)
Absorbance Accuracy : 0.002 (1 mm optical length)
Absorption Accuracy : 3%(at 0.64A at 350nm)
Limit of Detection : 2ng/pl dsDNA
Max. Detection Concentration : 15000ng/ml dsDNA
Detection Time : <5 Sec.
Cuvette Mode
Heating Temp.( °C) : 37±0.5 null
Mixing Speed (RPM) : 150-850 null
Optical Length (mm) : 10,5,2,1 null
Limit of Detection : 0.4ng/ml dsDNA null
Max. Detection : 750ng/ml dsDNA null
Data Interface : USB
Wireless Connection : Wifi
Software Update : USB direct update
Accessory : Pipette holder
Power : AC110V-220V 50HZ/60HZ (Power adapter)
NET Weight : 2.1KG / 2.0KG
