Order Code: 58011
Category: Chemistry Lab
SALIENT FEATURES : High quality xashing xenon lamp which can start to test directly without preheating. Powerful functions like Photometric measurement, Quantitative measurement, Kinetics, Spectrum Scan, DNA/Protein test, Multi-wavelength tes...
SALIENT FEATURES :
TECHNICAL SPECIFICATION |
|
Optical System |
Double Beam, Grating 1200 lines/mm |
Wavelength Range |
190 nm-1100nm |
Spectral Bandwidth |
1 nm |
Wavelength Accuracy |
±0.1nm656.1nm, ±0.3nm@all |
Wavelength Repeatability |
£ 0.1 nm |
Photometric Accuracy |
0.2%T(0~100%T),±0.002A(0-0.5A),±0.004A(0.5-1A) |
Photometric Repeatability |
£0.15%T(0-100%T), 0.001A(0-0.5A), 0.002A(0.5-1A) |
Photometric Range |
0-200%T, 0.3-3A, 0-9999C (0-9999F) |
Stray Light |
0.03%T@220nm, 360 nm |
Stability |
±0.0005A/h@500nm |
Baseline Flatness |
±0.001A |
Noise |
0.0005A@500nm |
Work Mode |
T%, Abs, Conc, Reflectance, E, |
Scanning Speed |
Hi, Med, Low (Max. 3000nm/min) |
Wavelength Setting |
Auto |
Display |
10.1" TFT Colored Capacitive Touch Screen |
Light Source |
Imported Xenon Lamp |
Detector |
Imported Silicon Photodiode |
Cuvette Holder |
10mm single hole cell holder |
Output |
USB drive, USB host, Rs232 |
Power |
AC 220V/50Hz or AC 110V/60Hz |
Shipping Size |
810x660x390mm |
Gross Weight |
27kg |
Standard Accessaries |
10mm glass cuvette x 4, 10mm quartz cuvette x2, Power cord, User's Manual, PC software |
