DC Motor Speed Control Trainer

Order Code: 21225385.88

Category: General Lab Equipment I

Trainer kit to verify  Fundamentals of speed control system with PT behavior  Open loop controls response  Effects of different controller parameters and methods on the response of the closed loop system  Recording of ...



SPECIFICATION

Trainer kit to verify

  •  Fundamentals of speed control system with PT behavior
  •  Open loop controls response
  •  Effects of different controller parameters and methods on the response of the closed loop system
  •  Recording of step responses (reference variable, disturbance variable)
  •  Study of Controller Optimization Specs
  •  Basic Unit with USB Port
  •  Motor
  •  Generator
  •  Analogue Tachometer
  •  P, PI, PID and switching controller Software

Kit contains :

  •  Training System
  •  Lab manual
  •  Instructor’s guide
