8085 Microprocessor Trainer
Order Code: 43219
Category: Embedded Trainers
43219 is a single board Microprocessor Trainer Kit based on 8085 Microprocessor, which is widely used to train engineers to develop software/ hardware for any industrial process & control. This Kit consists of power-full Monitor EPROM, ...
SPECIFICATION
- 8K bytes of EPROM with 8K bytes of battery backup RAM.
- 48 I/O Lines, Three Channel Timer/Counter, PC Serial Interface.
- Seven Segment Display with 28 Keys Hex Keypad.
- Power-full Command like Single Stepping, Break Point, Full Clock Execution, Examine Memory/ Register.
- Uploading & Downloading to and from PC in Windows 98/XP/NT.
- In-Built Power Supply.
- Based on 8085 CPU operating at 6.144 Mhz.
- 8K bytes of Powerful Monitor Program using 27512 EPROM
- 8K bytes of RAM using 6264 with Battery Backup using NICD Battery.
- On-board one memory expansion up to 56KB.
- Three Channel Timer/Counter using 8253 brought out at 10 Pins FRC Connector.
- 48 I/O lines provided through two nos. of 8255 brought out at 26 Pins FRC Connector to interface with IC-XX Series.
- RS-232C interface through SID/SOD lines
- Two mode of commands:
- Hex Key pad Mode
- Serial Mode
