Digital IC Trainer
Order Code: 24257784.18
Category: General Lab Equipment V
Should be a single board system capable of covering minimum 10 Experiment Should be designed using a Lattice CPLD Chip LC4128ZE covering all the Digital IC's as mentioned in the specification ...
SPECIFICATION
-
Should be a single board system capable of covering minimum 10 Experiment
-
Should be designed using a Lattice CPLD Chip LC4128ZE covering all the Digital IC's as mentioned in the specification
-
On-board Power supply (7.5V,300mA)
-
Multimedia Interactive e-manual to be provided on CD with Theory, Circuit Diagram and animations and experiments
-
Basic logic gate IC's:
1. NOT (7404) and OR (7432)
2. AND (7408) and NOR (7402)
3. NAND (7400) and EX-0R (7486)
-
NAND and NOR gates as Universal Logic Gates
-
TTL to CMOS and CMOS to TTL Interface
-
Half Adder, Full Adder, Half Subtractor, Full Subtractor
-
Basic Flip-Flops:
1. RS (using NOR) and JK (7476)
2. D (7474)
3. MS-JK (7476)
4. D (7474) and T (using JK)
-
Counters
1. Synchronous Binary Counter (74191)
2. 4 Bit Ring Counter using 7476
3. Decade / BCD counter using 7490
-
Universal Shift register 74194
-
9 bit parity Generator / Checker (74280)
-
Multiplexer (74153) and Demultiplexer
-
BCD to seven segment decoder (7447) & Seven segment display
-
4 bit Comparator (7485)
-
Binary to Gray, Gray to Binary, Binary 20 pin ZIF socketto BCD, BCD to Binary, BCD to Excess 3, Excess 3 to BCD
-
6 switches to provide Logic 0 & 1 inputs 16 LEDs to observe the output logic states
-
Manual clock, present and clear to observe the counter operation
